Landfill Gas Extraction Well Design: Guidance and Practical Experience

Landfill gas extraction well design starts with the conditions at the landfill and the purpose of the collection system. Published guidance provides an important reference, but applying it successfully also requires an understanding of drilling, waste behaviour, settlement and the practicalities of operating the installation.

This article brings together current published guidance and observations from my landfill engineering experience. It distinguishes regulatory requirements, published design advice and practical approaches that need to be judged against the circumstances of each site.

Where to Find Current Landfill Gas Well Design Guidance

For sites in England, start with the Environment Agency’s guidance on designing and building a landfill, its landfill gas management guidance, and the site’s environmental permit.

Landfill extraction well imageFor US projects, EPA’s Landfill Gas Energy Project Development Handbook, particularly Chapter 7, provides information on collection-system design and installation. EPA describes that chapter as general technical information rather than official regulatory guidance. Applicable federal, state and local requirements must be checked separately.

Requirements elsewhere in the UK and in other countries should be checked with the relevant regulator. Guidance written for England should not automatically be presented as a rule applying throughout the UK or Europe.

Practical perspective: A published detail does not establish how easily it can be installed, maintained or replaced in a particular waste mass. The designer needs to understand both the required outcome and the difficulties the drilling contractor and operator will encounter.

Site Information Before Well Design

The Environment Agency’s design guidance requires consideration of well positions, dimensions, connection pipework, cap interfaces and maintenance. These should form a coordinated design.

Before setting out the wells, assemble:

  • An up-to-date topographical survey.
  • Waste-placement records and information on remaining filling phases.
  • Reliable levels and locations for the basal lining and buried infrastructure.
  • Available gas, liquid-level and settlement records.
  • Information on existing wells and their operating performance.

This article is an update on one I wrote back in 2012. The original article emphasised obtaining good survey and development information. That remains sound practical advice: apparent precision in a drawing is of little value if the underlying site information is uncertain.

Well Layout and Spacing

EPA’s Chapter 7 explains that well spacing depends on the effective influence of each well and may vary across a landfill. The collection objective also matters: a system supplying renewable natural gas equipment may need a different arrangement from one principally controlling emissions.

My original example described perimeter wells approximately 40 metres inside the boundary, spaced at 40-metre centres, with around 50-metre spacing in central areas. Those figures illustrate the approach discussed at the time; they are not a standard layout for every landfill.

Practical perspective: In simpler circumstances, experience-based layouts could provide a sufficient working solution. Retaining that experience is useful, but the designer must assess whether the present site behaves similarly. A geometrically regular layout does not guarantee uniform collection from non-homogenous (heterogenous) waste.

Drilling Depth and Bore Diameter

EPA’s handbook emphasises using reliable liner-level information and maintaining a protective separation between drilling and the lining system. Uncertainty in the records needs to be addressed before drilling begins.

The intention when drilling from the surface to install landfill gas wells, is to drill down to the base of the landfill. This must be understood as reaching the intended depth within the waste while protecting the lining. Care must be taken to ensure that the drill stops above the liner, and not drilling until the liner is encountered.

The original article suggested an approximate 325 mm bore diameter was a practical example. Bore and casing dimensions need to suit the well depth and the proposed construction and maintenance arrangements.

Practical perspective: The drilling proposal must be workable in the material actually encountered. Discuss the installation with an experienced contractor, while keeping responsibility for design decisions and changes clear.

Avoiding Excessive Air Ingress

England’s current gas-management guidance requires the collection system to be monitored and adjusted to maximise recovery while minimising air entering the waste.

The original article warned particularly about excessive extraction near the perimeter. That concern remains relevant. Increased flow after applying more suction does not, by itself, demonstrate improved methane recovery.

Practical perspective: Operating judgement matters. Readings need to be interpreted together and in the context of changes to the well, cover and surrounding landfill, rather than treating one instrument reading as the whole answer.

Gravel Packing: Published Practice and Site Experience

EPA’s handbook describes aggregate backfill as part of gas-collector construction. It would therefore be misleading to describe an unfilled annulus as the normal arrangement everywhere, as we did in our original article.

However, my original reservations about gravel packing concerned settlement, and damage to well pipework during settlement, if the packing adheres too closely to the lining pipe preventing the landfilled waste slipping down the pipe within the borehole. If, during landfill settlement, movement between the extraction well lining and the waste cannot occur due to excessive friction the extraction well lining will fail and the gas flow may cease. Those observations should not be ignored, however, it is acknowledged that other published arrangements show gravel packed around the annulus.

Practical perspective: Assess the pack, casing, seals and settlement behaviour together. A construction detail needs to perform over time, not merely appear satisfactory when installed. The earlier observations explain a failure concern; they should not be read as a universal prohibition on gravel-packed wells.

Leachate, Well Pipework and Maintenance

The earlier article discussed filter fabrics becoming blinded and flexible pipework bending enough to obstruct pump removal. These are practical considerations when selecting a well construction.

For a well intended to accommodate pumping equipment, consider access and removal as part of the design. Where gas and liquid-management functions are combined, explain how both will be maintained.

Practical perspective: An installation that works initially but cannot be serviced may create a substantial operating problem. Product selection should include the experience of those who will install and maintain it.

Wellheads, Capping and Settlement

The Environment Agency’s design guidance identifies settlement accommodation, including suitable slip joints or flexible connections, as a consideration. It also addresses cap interfaces and condensate drainage.

The sleeved wellhead described in my original article was intended to reduce stresses as settlement occurred. That remains a useful design objective.

The earlier reference to a cap approximately 2.5 metres below ground level described a particular arrangement. Actual cap levels and connection details must come from the site design.

Gas Collection Requirements in the United States

US federal landfill gas controls do exist. The earlier statement that there were no equivalent federal regulations was too broad and is corrected here.

EPA explains that applicable municipal solid waste landfills must collect and control gas under the Clean Air Act. Energy recovery is not a universal federal requirement; available control routes include flaring, energy use or treatment for subsequent use. Applicability depends on the relevant rules and landfill circumstances.

See EPA’s frequently asked questions about landfill gas. This correction does not imply that US federal controls were introduced only after the original article.

Flaring, Minimum Flows and Financial Incentives

In England, Environment Agency guidance requires energy recovery where possible, with flaring or other appropriate treatment where it is not. The site permit and agreed gas management arrangements remain important.

The original lower threshold figure of 100 m³/h flow before installing flaring should not be used as a general minimum. Likewise, the earlier reference to engines operating below that flow is not a universal feasibility rule. Check equipment-specific operating limits, gas quality and the expected variation in supply.

Historic rules of thumb can help explain project scale, but equipment selection needs a firmer basis. Ensure quoted flows use consistent reference conditions.

The earlier US tax-credit figure of 1.1 cents per kWh and associated 150 kW condition should not be used as current financial assumptions. Check the eligibility and terms of any incentive available to the actual project.

Further Practical Design Guidance

My Landfill Gas Extraction Well Design Techniques & Methods guide explores these decisions in more detail, including vertical and horizontal collectors, sealing, settlement, liquids, installation and wellfield operation.

View the complete landfill gas extraction well design guide.

Historical Note: The Original Article and This Update

This article was originally published on 24 November 2012 to make practical landfill gas design experience accessible to readers.

Things have moved on, and I accept that new methods and ways of thinking deserve consideration. However, in the simpler circumstances addressed by the original article, my experience was that practical arrangements such as those described would work and be sufficient.

This update preserves those observations while identifying their context. Published guidance is an important reference, but it does not replace practical knowledge of what happens during drilling, installation and operation. Equally, experience from one landfill needs careful interpretation before being applied to another.

Updated 30 October 2026: current references added, historical examples clarified, and the US regulatory statement corrected.

Frequently Asked Questions

What spacing should landfill gas extraction wells have?

There is no single spacing suitable for every landfill. Use the site conditions, collection objectives, applicable guidance and operating evidence to develop the layout. The dimensions in the original article are examples, not a universal specification.

Should gas extraction wells be gravel packed?

Aggregate-packed constructions are described in EPA’s handbook. My earlier observations highlight settlement concerns that should also be considered. The appropriate arrangement depends on the complete well design and the site.

How deep should a landfill gas well be drilled?

The design must establish a suitable extraction depth and protect the lining and other infrastructure. Do not interpret a general description of drilling towards the base as an instruction to drill up to the liner.

Do US federal regulations require landfill gas control?

Yes, applicable municipal solid waste landfills are subject to federal gas collection and control requirements. Check which rules apply to the particular landfill, together with state and local requirements.

Does this article provide a construction specification?

No. It explains design considerations and practical experience. Construction requires a site-specific design, appropriate working arrangements and compliance with the applicable permit and requirements.
